Polyol-ether Borate Ester For Breaking Fluid
Product introduction
This polyol-ether borate, with very high dry and wet boiling points as well as excellent low temperature kinematic viscosity, is designed to provide a solution for brake fluid boiling point retention and product water-resistant effect, minimizing the effects of water or water absorption in the brake fluid. In a suitable base fluid, the kinematic viscosity of the brake fluid produced at -40℃ is between 800mm2/s and 1400mm2/s, and the wet boiling point is above 180℃.
Application:
Polyol ether borate in appropriate polyether or additives, can be blended to meet the standards: GB 12981-2012HZY3、HZY4、HZY5、HZY6；
FMVSS：Federal Motor Vehicle Safety Standard
FMVSS is the minimum requirement for vehicle safety in the United States.The requirements for brake fluids in the standard are defined by the DOT Classification standard.
FMVSS No.116 DOT3、FMVSS No.116DOT 4、FMVSS No.116 DOT5.1 do not contain silicon.
The recommended dosage is above 30% for HZY4, DOT4, J1704, and BF-4,
70% for DOT5.1and 80% forDOT6.
International standards for brake fluid
SAE: Society of Automotive Engineers
SAE International is the leading organization for research and development of standards for the U.S. transportation industry.
SAE J1703, SAE J1704 standards.
ISO: International StandardizationOrganization
ISO strives to harmonize various issues related to industry standards around the world, with the ultimate goal of publishing international standards.
ISO 4925 Class 3, ISO 4925 Class 4, ISO 4925 Class 5-1, ISO 4925 Class 6.
GB: Pinyin acronym for GuoBiao, which means China's mandatory national standard.
National standards in China are formulated by the standardization administrative department under the State Council. The requirements for brake fluid in the standard are defined by the HZY classification standard.
GB 12981-2012 HZY3, GB 12981-2012 HZY4, GB 12981-2012 HZY5, GB 12981-2012 HZY6.
JIS: Japanese Industrial Standard
JIS is responsible for setting JIS K2233 Class 3, JIS K2233 Class 4, JIS K2233 Class 5, JIS K2233 Class 6.
Performance:
| Item | GHB295 | GHB300 | GHB210 |
|---|---|---|---|
| Appearance | Colorless to light yellow transparent liquid | Colorless to light yellow transparent liquid | Colorless to light yellow transparent liquid |
| Dry the boiling point °C | 295 | 300 | 310 |
| Wet the boiling point °C | 215 | 205 | 219 |
| Kinematic viscosity（mm2/s，-40°C） | 950 | 1426 | 1659 |
| Density（20°C）kg/m³ | 1.0410 | 1.0410 | 1.0410 |
| PH | 4.43 | 4.63 | 4.54 |
| Rubber swelling（%，120°C，70hr） | 3.0 | 3.0 | 3.0 |
| Low temperature fluidity（-50°C x 6hr/s） | pass | pass | pass |
Package/storage/transportation:
Packing details: 200L/Iron drum, or as per customer’s request; IBC; marks/retention sample/acceptance of delivery according to SHO164 standard.
Storage conditions:
The recommended maximum operating temperature should not exceed 75°C;
The maximum long-term storage temperature should not exceed35°C.
Storage life: 2 years (10~35°C temperature)
Transportation: highway drum/railway tanker/highway tanker.
